Yamaha | TG33 |
|
Description | The SY22 is one of these digital synthesizers with a thin metallic sound. It uses a synthesis method known as vector synthesis (similar to that on the ProphetVS and Korg Wavestation) in which samples and FM sounds (adapted from Yamaha's DX line) are altered and combined using the on-board joystick to create new and often interesting sounds. Joystick moves can be recorded and repeated too, a feature rarely seen until the JP-8000 came! There is no filter, no resonance, no ring modulator sand no sign of any arpeggiators or sequencers on-board. Although this is unfortunate, its strengths lie in its ability to record data manipulation in real-time and its multitimbrality - both of which lend themselves to creating some complex and cool sounds perfect for ambient, dub and industrial styles. It also has a drum kit sound set and simple built-in effects. A desktop module version of the SY22 is the TG33 which also has increased memory . |
| Brand | Yamaha |
| Model | TG33 |
| Device | Synth |
| Type | Desktop |
| Engine Type | Digital |
| Engine | AWM, FM |
| Voices (max) | 32 |
| Multitimbral | 8 |
| Oscillators | 4 |
| LFO | AM, PM, Saw Up, Saw Down, Triangle, Square, Sample & Hold |
| Engine Detailed | 2 Digital FM operators + 2 AWM (using 12-bit ROM samples) |
| FX | 16 Digital Reverbs and Delays |
| Memory | 128 preset, 64 user |
| Keys | 0 |
| Key type | N/A |
| Velocity | N/A |
| Aftertouch | N/A |
| Midi | I-O-T |
| Produced: | 1990 - 1990 |
| Legend: | Obvious | Y: Yes, N: No, N/A: Not Applicable | |
| VCO | Voltage Controlled Oscillator | DCO | Digital Controlled Oscillator |
| LFO | Low Frequency Oscillator | Sub | Sub Oscillator |
| VCF | Voltage Controlled Filter | VCA | Voltage Controlled Amplifier |
| Velocity | As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key. | Aftertouch | Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel. |
| Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise. | |||
