Korg | DDD-1

Description

The DDD-1 is a digital programmable drum machine from Korg from the mid-eighties. It offers 18 electronic drum sounds with a sound that is typical of this era. Basic kicks, snares, toms, rimshot, closed hi hats, open hi hats, ride, crash, claps, cowbell, tambourine and cabasa. Additional sounds can be added using ROM cards. The DDD-1 also featured a sampling option allowing very short and limited sampling for that extra edge of unique sounds to add to your drumkit. Drum sounds can be triggered from the 14 assignable velocity sensitive trigger-pads and there are some individual outputs.

Programming the DDD-1 is fairly straight forward. Memory holds 100 patterns which can be linked or chained to form songs, for which there are 10 song memory locations. The drum sounds have editable parameters such as decay and tuning. For added groove in your patterns there are Roll and Flam effects. The DDD-1 is equipped with full MIDI implementation making it an easy drum machine to use in any MIDI studio. If you like typical eighties drum sounds, the DDD-1 would be a formidable alternative to other similar drum machines like the Roland TR-707 and offers more professional features than its counterpart, the DDD-5.

BrandKorg
ModelDDD-1
DeviceDrum
TypeDesktop
Engine TypeDigital
EnginePCM
Voices (max)12
Engine Detailed18 sampled sounds: 2 Kick, 2 Snare, Low/Mid/Hi Toms, Rimshot, Claps, Crash, 2 Open hihats, 2 Closed hihats, Ride, Cowbell, Tambourine and Cabasa
SamplerY
Memory100 Patterns, 10 Songs.
Keys14
Key typeButtons
VelocityY
AftertouchNo
MidiI-O
Produced:1986 - 1987
Legend: Obvious Y: Yes, N: No, N/A: Not Applicable
VCO Voltage Controlled Oscillator DCO Digital Controlled Oscillator
LFO Low Frequency Oscillator Sub Sub Oscillator
VCF Voltage Controlled Filter VCA Voltage Controlled Amplifier
Velocity As with a piano, the harder you hit a key, the louder the sound, unlike most organs which always produce the same loudness no matter how hard you hit a key. Aftertouch Pressing a key after you activated it. Channel Aftertouch, no matter which key, it will send a Channel message. Poly Aftertouch, sends the pressure per key instead of the whole channel.
Values for OSC, LFO, Filter, Envelope are per voice unless stated otherwise.
